Key Features

• SPD & DC Switch Built in TYPE II SPD for DC and AC both & DC switch for solar DC disconnection
• IEC Certified IEC 62116, IEC 61727, IEC 61683, IEC 60068(1,2,14,30), IEC 62109-1/2, EN 61000-6-1,6-2,6-3,6-4
• LCD & LED Display LCD display for checking generation data with LED for fault, alarm indication
• Warranty 10 Year warranty
• Weight : 20  kg
• Maximum Efficiency : 98.3 %
• Self Consumption at Night : < 1  W
• Cooling : Natural
• Degree of Protection : IP 65
• Dimension : 52 cm x 43 cm x 18.9 cm
• Operating Temperature Range : -25 °C to +60 °C
• Topology : Transformer less
• Max Input Current Per MPPT : 26  A
• Maximum DC Input Short circuit Current Per MPPT : 36  A
• Maximum Input Voltage : 1100  V
• Number of MPPT String Per MPPT : 2 / 2+2
• Rated Input Voltage : 650  V
• Grid Frequency Range : 45 Hz - 55 Hz
• Grid Voltage Range : 310 V AC - 480 V AC
• Maximum AC Power : 16500 VA
• Maximum Output Current : 23.9  A
• Nominal Grid Voltage : 3/N/PE, 220 V AC / 380 V, 240 V AC / 415 V AC
• Rated Output Current : 23.9  A
• Rated Power : 15000  W
• Over Voltage, Over current, Earth Fault Protection : Yes
• SPD : Type II SPD
• Anti Islanding DC Reverse Polority Over Temperature : Yes
• Recommended Maximum PV Input Power : 22500 Wp
